2 Head Paper Tube Making Machine, KS-100

Main parameters
Paper layer 2-9 layers
Inner core diameter 20-80 mm
Thickness 1-5 mm
Winding speed 0-25 m/min
Cut-to-length mode Numerical control
Winding head Two heads
Cutting method CNC automatic cutting by circular knife
Gluing method Double-sided gluing
Control method Frequency conversion control
Input voltage 380V/220V
Number of operators 1-3
Total weight 2800 kg
Configurations
Main motor power 7.5 kW
PLC controller weikong
HMI weikong
Frequency converter ENERGY
Electrical components Omron/Chint
Signal element Omron/Pefun
Button/emergency stop Siemens
Pneumatic Components Airtac/tianao/detai/chengdi
