Folder Gluer for Straight Line and Crash Lock Bottom Boxes

Folder Gluer for Straight Line and Crash Lock Bottom Box

This is our folder gluer for straight line and crash lock bottom boxes. The machine is specially designed for paperboard shaping and adhesive application after box cutting. The equipment is highly versatile and can be used to fold and paste various straight seam boxes and bottom edging boxes.

Request a Quote

Technical Parameters

Power capacity: 6.5KW 380V
Overall size (mm): 9000 x （1100）1300 x 1350
Weight (kg): 2600

KSHH-800AG
Type of box	Amax	Amin	Bmax	Bmin	Cmin	Dmin	Fmin
No-edged bottom box	700mm	110mm	600mm	110mm	8mm	70mm	51mm
Edge bottom box	700mm	160mm	570mm	180mm	9mm	90mm	85mm

KSHH-1200AG
Type of box	Amax	Amin	Bmax	Bmin	Cmin	Dmin	Fmin
No-edged bottom box	1200mm	110mm	800mm	110mm	8mm	70mm	51mm
Edge bottom box	1200mm	160mm	770mm	180mm	9mm	90mm	85mm

The Machine Package Size

Model	Size(LWH)(mm)	Weight(kg)	Volume (㎡)
KSHH-800AG	282011301400	920/850	4.46
	275011601250	1050/920	3.99
	2680×1030×1040	650/580	2.87

Model	Size(LWH)(mm)	Weight(kg)	Volume (㎡)
KSHH-1200AG	282013701240	1020/910	4.79
	275013801250	1150/980	4.74
	2680×1110×1040	680/600	3.09

Details

Baiying Carton Machinery is a reliable manufacturer specializing in high-performance corrugated board and corrugated box making machines. With 20 years of technical expertise, we provide complete production solutions, including 2/3/5/7-ply corrugator lines, high-speed flexo printer slotter die-cutters, and automatic folder gluers. Our specialized portfolio extends to paper tube making machines and glue trap board production lines. Having exported 95% of our equipment to over 20 countries—including the USA, Russia, and India—we focus on delivering durable, high-precision machinery that meets rigorous industrial standards for professional packaging plants and high-volume box factories worldwide.
